Xérus data management system central unit
Key parameters:
Based on an efficient architecture and latest state of the art components.
Fully modular and expandable.
Fully programmable.
Recording frame up to 16 measured channels
Features
Recording frame: up to 16 measured channels digital or analog
On board 3 axis low G accelerometers and altitude transducer
4 analog inputs through submini connectors (Air speed, PwP current+voltage, Auxillary)
1 rpm
input
1 transmitter ouptut connector
1 dedicated GPS connector
1 isolated connector to an RC channel
1 digital extension connector
dimension : 52x 38mm
Ultra thin:only 9mm thickness maximumWeight : 12 gr
Standard sampling frequencies: 20 - 10 - 5 - 2 - 1 Hz ( 5 Hz and 2 Hz are prefered frequencies from experience)
Recording duration:
5 channels 43 minutes @ 5Hz
12 channels 18 minutes @ 5 Hz
Start-stop function12 channels 18 minutes @ 5 Hz
Current on board calculation for transmission to Lynx HUD:
- Altitude
- air speed
- Yaw
- Distance over longitude
- Distance over latitude
- more to come..
.
